Main features
Process inputs:
1 temperature probe input
- Thermocouples: J, K,
- RTD: PT100
- Overall Accuracy : ± 2% fs
- Measurement range:
Depending on the probe and range used
Range available from 100 to 1200°C
Process output:
- 1 output relay 8A-AC1 (3A-AC3)/250 Vac or
- 1 output to drive SSR (0-12 Vdc)
Power supply:
24… 240 Vac ±10%
Functions:
Control mode:
- ON/OFF
- PROPORTIONAL
Installation:
Mounting method: panel mount
Case dimensions: 48 x 48 x 70.6 mm
Connections:
fixed or plug-in screw terminal block for 0.2..2.5 mm2 / AWG 24...14 cables or Octal socket
Front protection:
IP 54 mounted in panel with gasket
